    Aluminium Driverless Led Module Ac 180-300v Bulb Dob Led Light Module

    Ask Lasest Price
    Brand Name : RYGH Tech; OEM or ODM available
    Model Number : RYGH804C-FL150W-2835-198-V3.0
    Certification : CE, ROHS
    Price : negotiable
    Payment Terms : T/T, Western Union,Paypal, MoneyGram
    Supply Ability : 5000 pieces/quarter
    Delivery Time : Sample order 5-7 days, Bulk order 7-15 working days
    • Product Details
    • Company Profile

    Aluminium Driverless Led Module Ac 180-300v Bulb Dob Led Light Module

    AC 180-300V bulb DOB LED Light module led light for flood light

    The DOB is configured to arrange the LED light source and the driving circuit on the same substrate. The HVLED can connect the light source in series with the mains, so that the number of parts of the LED driving circuit can be reduced, thereby saving space. Seoul's Acrich technology is also a high-voltage LED + segmented constant current IC drive mode, which is the same concept as the DOB (Driver on board) technology on the market.


    Part no.RYGH804C-FL150W-2835-198-V3.0
    LED Power150Watt
    VoltageAC 180-300V
    Light SourceTaiwan (Vendor of Aurora)
    Power FactorFP>0.98
    Working Temperature-30-55℃
    Dimen-sion (mm)W202mm*192mm
    CCT2700K-7000K
    Components life time100,000 hrs
    CRI>80
    Beam Angle120°
    ChipEpistar 2835, Osram 2835
    MaterialAL thermal conductive 1.6
    LED Quantity198pcs
    FlickerYes
    Warranty5 Years


    Our Advantages:

    Advantages:
    1, Our engineer has 15 years experience in led lighting field
    2, 6 years focus on AC linear led lighting
    3, 3nd Generation Linear IC from Top Taiwan Team-Vendor of AURORA Lighting
    4, Driverless led lighting already worked 4-5 years all over the world, failure rate <0.5%, you can sleep well at night because very few complaints
    5, Working voltage max 300V, other company max 265V
    6, With Over voltage protection, over temperature protection, short circuit protection, over load protection
    7, Pass Safety Certification, EMC/EMI
    8, 4KVA Surge Protecion on board, 6KVA and 6KVA SPD available
    9, 5 years warranty,
    10, Can be work in harsh environment from minus 30 degrees to 50 degrees
    11, High voltage, low working current, no capacitor, no shocking current when turning on, very few interference on power grid, low temperature on power lines
    12, Easy for maintenance, easy to change a DOB if failed
    13, 99.9% solid components, life time 100, 000 hours, much longer life time than LED
    14,much higher cost performance than MEANWELL driver, lumileds and OSRAM Chip warranty 5 years
    15, No spark when switching, , which can be used as explosion proof lighting
    16, We know and protect our product like our child, and vitnessed the change and improvement of our product in last 6 years
    17, We insist on updating our DOB Technology

    Application:

    High way/Park/Street/Roadway/Parking Lot/Public square/ plaza/Campus/Airfield/Farm & Ranch/Remote Area/Military Base/Goverment project for special use etc.


    Why choose us:

    Direct Marketing

    Timely feedback, sincere service

    TUV/ CE/RoHS/PSE/FCC Certificate

    Low Min Order Quantity

    100% QC Inspection

    Quantity Guarantee

    Free OEM&ODM Service

    Good After-sale Service

    100% QC Inspection
